1 Ton Kubota Mini Excavator Enclosed AC Cabin & Side Swing | AGT-KH18K-CC
4.9/5 243 reviews
$7,807.79
Professional equipment built for demanding jobs. 1 Ton Kubota Mini Excavator Enclosed AC Cabin & Side Swing | AGT-KH18K-CC AGT-KH18K-CC, with a 1-ton operating weight and 5.41-foot digging depth, is compact and reliable for maneuvering in tight spaces...
Credit cards & bank transfers accepted
Delivery estimateTypical delivery is 2–6 weeks
Freight coordinationDestination and unloading review
Warranty & supportProduct guidance beyond delivery
Equipment guidance
Practical help before you order.
Nationwide delivery
Freight coordinated to your location.
Freight coordination
Destination and unloading details reviewed with your order.
Product overview
Built for the work ahead.
Professional equipment built for demanding jobs.
1 Ton Kubota Mini Excavator Enclosed AC Cabin & Side Swing | AGT-KH18K-CC
AGT-KH18K-CC, with a 1-ton operating weight and 5.41-foot digging depth, is compact and reliable for maneuvering in tight spaces like farms, gardens, and parks, offering features like air conditioning, side swing, and an enclosed cab for a dust-free and comfortable work experience.
2024 Model
Technical Data:
- Operation Weight: 1 Ton
- Engine: Kubota Diesel Engine
- Equipped with Air Conditioned Enclosed Cabin
- Equipped with Side Swing
Engine:
- Brand: Kubota
- Model: D722
- Type: 3-cylinder diesel engine
- Power Output: 10.2 kW
- Maximum Speed: 3,600 RPM
- Emissions Compliance: Tier 4
Performance:
- Operating Weight: 980 kg (2,160 lbs)
- Maximum Digging Depth: 1,693 mm (66.7 inches)
- Maximum Digging Height: 2,560 mm (100.8 inches)
- Maximum Loading Height: 1,800 mm (70.9 inches)
- Minimum Rotation Radius: 3,060 mm (120.5 inches)
- Travel Speed: 0-1.8 km/h
- Climbing Ability: 15°
Dimensions:
- Overall Length: 2,925 mm (115.2 inches)
- Overall Width: 958 mm (37.7 inches)
- Overall Height: 2,422 mm (95.4 inches)
Hydraulic System:
- Main Pump Type: GP510803
- Rated Set Pressure: 25 MPa
- Maximum Flow Rate: 21.6 L/min
- Multi-Circuit Valve: 4 mechanical + 4 hydraulic
- Rotary Hydraulic Motor Type: BM2-315
- Traveling Hydraulic Motor Type: BM6-315
Additional Features:
- Cabin: Enclosed with air conditioning
- Side Swing: 30° angle
- Bucket Capacity: 0.03 m³
Specific Data:
| Operation Weight | 980kg |
| Engine | Kubota(D722) |
| Travel speed low/high (km/h) | 0-1.8 |
| Capacity of bucket | 0.03 m³ |
| ?Max Digging Depth | 1,693 mm |
| Max Digging Height | 2,560 mm |
| Max Load Height | 1,800 mm |
| Min Rotation Radius | 3,060 mm |
| Max Angle of Climb | 15° |
| Side Swing Angle | 30° |
| Total length | 2,925 mm |
| Overall width | 958 mm |
| Total Height | 2,422 mm |
| Maximum speed (rpm) | 3,600 |
| Rated set pressure (Mpa) | 25 |
| Maximum power | 10.2 |
| Main pump type | GP510803 |
| Maximum flow rate of main pump(L/min) | 21.6 |
| Multi circuit valve | 4 mechanical + 4 hydraulic |
| Rotary hydraulic motor type | BM2-315 |
| Traveling hydraulic motor | BM6-315 |
Need help choosing the right configuration? HyperLifts can help review your application, delivery requirements, and equipment needs before reservation.
CUSTOMER EXPERIENCES
Mini Excavators at Work.
See how compact excavators are being used for landscaping, trenching, property maintenance, drainage work, and small construction projects.
“Compact enough for our property but much more capable than I expected. It has been extremely useful for trenching and landscaping work.”
“The compact footprint made it practical to work around the house while still having the reach needed for trenching.”
“We needed a small machine for ongoing property work. The team helped us understand which size made the most sense.”
“A capable compact machine for smaller construction projects where access and working space are limited.”
“Delivery coordination was straightforward and communication was clear throughout the order.”
“The machine has been useful for drainage work and moving through areas where full-size equipment would not be practical.”
“The compact size has made it useful around the property for maintenance, cleanup, and light farm work.”
“Great size for residential projects where bringing in a full-size excavator is not practical.”
Delivery information
Freight planned for your destination.
Nationwide U.S. delivery is shipping only, with no pickup. Typical delivery is 2–6 weeks depending on equipment, inventory, ZIP code, and freight scheduling. Heavy equipment may require specialized freight coordination.
Ordering information
Order securely online.
Add this equipment to your cart and complete checkout at the displayed full price. Delivery details are confirmed as part of order processing.
Common questions
Before you order.
Can you help me choose the right Mini Excavator?
Our team can help compare machines based on intended use, project type, size requirements, delivery access, and budget.
How do I order this equipment?
Choose your configuration, add the equipment to your cart, and complete secure checkout at the displayed full price.
How long does delivery take?
Typical delivery may take approximately 2–6 weeks depending on equipment, inventory, ZIP code, and freight scheduling.
How is delivery arranged?
Freight transportation, destination access, unloading requirements, and expected timing are reviewed before delivery is scheduled.
